HOW OUR FURNACE TUBE INSPECTION SERVICE WORKS
4-in-1 Furnace Tube and Fired Heater Inspection Service with HEATER-PIG™
-
Crack Detection
-
Wall Loss Inspection
-
Geometry Inspection
-
Cleanliness and Decoking Verification
KEY BENEFITS AND CAPABILITIES
4-in-1 Run Combined Technology
Crack,Wall Loss,
Geo & Decoking Verification
360 Degree
Phased Array Sensor
100%
Pipe Wall Coverage
2" - 12"
Tube
Diameter Sizes
Bi-Directional
Inspection
Capability
Multi-Diameter
Tube
Capability
24 Hour Rapid Reporting and On-Site Viewing
Plug Header, Mule Ear and
1D Bends
Rapid and Easy Aircraft Mobilisation
TECHNOLOGY TO MAXIMISE YOUR ASSETS PRODUCTIVITY
Heater-Pig™ 4-in-1 Phased Array UT inspection tool directly contributes to increased bottom-line revenue for your asset by optimising efficiency and minimising downtime. By integrating multiple technologies into a single run, it drastically reduces the time the asset needs to be out of service compared to options on the market.
OPERATIONAL BENEFITS FOR CHALLENGING FURNACE AND FIRED HEATERS
HEATER-PIG™ is lightweight, modular, and can be rapidly mobilised, often by aircraft, making it ideal for challenging inspection environments around the world. Additional pods can be synchronised to extend pipeline run length, giving unmatched flexibility in inspection campaigns.
CUTTING-EDGE PAUT
SENSOR TECHNOLOGY
The integrated 360 degree circular Phased Array UT sensor provides sub mm accurate ultra-high resolution defect detection capability along with the ability to send simultaneous straight and angled ultrasonic beams for combined crack detection, wall loss and geometry.
RAPID REPORTING AND
ON-SITE DATA VIEWING
VECTOR-VIEW™ is our advanced Phased Array UT data analysis and reporting platform which provides instant on-site data viewing and produces final reports in under 24 hours. When more thorough reports are required the platform can produce Fitness-for Service reports to give more insight into asset health.
GET A QUOTE FOR OUR
TUBE INSPECTION SERVICE
INSPECTION SPECIFICATIONS
TUBE AND COIL
APPLICATIONS
Vacuum Heaters (VDU)
Crude Heaters (CDU)
Delayed Cokers (DCU)
Visbreakers
Charger Heaters
Pre-Heaters
HRSG
OTSG
Steam Generators
All Types of Coils
Furnaces
Boilers
Fired Heaters
Steam Crackers
Steam Reformers
Process Heaters
Serpentine Coils
Any Many More...
ANOMALY
DETECTION
Abrasive Wear
Buckles
Corrosion and Clusters
Weld Penetration
Cracks
Dents & with Metal Loss
Erosion
General Wall Loss and Thinning
Gouges or Scratches
Hotspots
HIC
Laminations
Ovality
Manufacturing Anomaly
Fretting
Historic Repairs
Schedule Changes
Creep
Swelling and Bulging
Stress
Wrinkles
Any Many More..
